Workpiece Fixturing

Whether for tactile, optical or X-ray applications: Fixing the component on the measuring device is decisive in order to achieve meaningful and accurate measuring results. ZEISS clamping devices and accessories are designed to be universal: They are suitable for a wide variety of geometries and measuring devices. You can choose from well thought-out kits, the components of which can also be purchased separately, as well as universal clamping devices such as vices and three-jaw chucks.
OmniFix Vise, 170 x 420
626109-9220-280
17.284,00 krSales tax not included
 Express: Shipment today
 Delivery information
211,00 krSales tax not included
 Shipment within: 1 day
13.851,00 krSales tax not included
 Shipment within: 2 days
7.507,00 krSales tax not included
 Shipment within: 2 days
22.103,00 krSales tax not included
 Shipment within: 2 days
10.359,00 krSales tax not included
 Shipment within: 2 days
OmniFix Vise, 170 x 320
626109-9220-270
17.168,00 krSales tax not included
 Shipment within: 22 days
Column D10 M6 MF - L22,5
600062-0215-026
Length (L)
22,5 mm
113,00 krSales tax not included
 Shipment within: 2 days
Styrofoam block, 15° B120
626140-9311-120
920,00 krSales tax not included
 Shipment within: 2 days
687,00 krSales tax not included
 Shipment within: 2 days
Clamp or hold?

Clamp or hold?

Clamp or hold: These are the variants used to position components for measurement. Frictional clamping devices are used when probing forces are applied in tactile metrology or machine movements can influence the position of the workpiece (e.g. active damping). In optical metrology or CT applications the body is held, i.e. brought into a defined position, without exerting force. This corresponds to the VDI guideline 2860, among others.
Statically determined

Statically determined

In all cases, the aim is to achieve static determinacy: For non-deformable workpieces, static under-determinacy is avoided by defining them in all six degrees of freedom - translatory in three directions and rotary around three axes. For deformable workpieces, such as objects made of sheet metal or plastic that deform before assembly, static overdeterminacy must be avoided.
